Product Description:

Assun driver integrated series BLDC motors are equipped with the speed driver inside of the motor for easier installation and more convenient use.Basic functions like speed control, rotation control and signal feedback can be achieved by the integrated driver.

Product introduction:

AM-BD2845AN-1810.

1.Weight :140.1g.Maximum power output 58.0W.

2. No load speed ±12%: 9680rpm. No load current Max150%: 120mA .

3.Torque constant 17.6mN.m/A. Speed constant 543rpm/V, Speed / torque gradient : 42.3rpm / mN.m

4.Diameter 28mm. Length 45mm.DC Brushless Driver Motor,3000-15000rpm.18V.24V.12V.

5. Maximum winding temperature: 85℃,Ambient temperatue range : -30 to 65℃.Motor thermal resistance : 10.25K/W.

6.DC Brushless driver motors can install the corresponding with encoder and planetarty gearbox.

Product Details:

Recommended Gearbox:

Planetary gearbox: AM-32GP. AM-28GP.

Recommended Encoder :

Encoder S: AM-EN1611S**

2~3 Channels

Encoder T: AM-EN1612T**

2~3 Channels

Appliation:

Assun Motor application of positive element brushless precision servo motor in intelligent equipment

Motor data tested at 25℃.Motor operation exceeding continuous limits will reduce life or result in damage.

At elevated ambient temperature.load current must be reduced.
