12V 24V 36V Brushless DC Coreless Motor 15000rpm 36mm Diameter 60mm
Length
12V,24V,36V DC Brushless Motor,10000-15000rpm,36mm diameter,60mm
Length
Product introduction:
1. It's DC Brushless Motor. 10000-15000rpm,36mm diameter.60mm
Length,12V,24V,36V
2. No load speed ±12%: 11200rpm. No load current Max150%: 320mA
.Maximum power output 178.1W. Terminal resistance ±12%: 0.2Ω.
3. Torque constant 10.2mN.m/A. Speed constant 938rpm/V,
4. Brushless motors can install the corresponding with planetarty
gearbox and encoder
5. Weight :325.8g. Ambient temperatue range : -30 to 65 ℃.
Product Details:
| Motor Model | AM-BL-3660AN-1211 | Unit |
| Nominal voltage | 12 | V |
| No load speed ±12% | 11200 | rpm |
| No load current Max150% | 320 | mA |
| Max cont.torque | 47.6 | mN.m |
| Rated Speed | 10322 | rpm |
| Rated Current | 5000 | mA |
| Rated Power | 51.5 | W |
| Starting current | 60000 | mA |
| Stall Torque | 607 | mN.m |
| Maximum power output | 178.1 | W |
| Maximum Efficiency | 86 | % |
| Terminal resistance ±12% | 0.2 | Ω |
| Inductance ( 1KHz ) | 0.027 | mH |
| Mechanical time constant | 3.2 | ms |
| Moment of inertia | 16.75 | gcm² |
| Torque constant | 10.2 | mN.m / A |
| Speed constant | 938 | rpm / V |
| Speed / torque gradient | 18.4 | rpm / mN.m |
| Weight | 325.8 | g |
Service idea :
We can search for qualified products according to the required
specifications (size, torque, revolutions, etc.) of gearbox, DC
motor and reducer proposed by customers. The products searched are
just one example of a rich product lineup, and there are many
products that have not been published. At the same time, we also
undertake special product design and OEM development. For relevant
matters, please contact the business department of our company.
